9000 Control Valve Assembly
Item No.
Quantity
Part No.
Description
.
1.........................1...........................14861-01.........................
Valve Body, 9000, Machined w/O-ring
.
.
.
40688...............................
Valve Body, 9100
.
2.........................1...........................14914...............................
Piston, 9000, Upper
.
3.........................2...........................14309...............................
Retainer, Piston Rod
.
.
.
16590...............................
Retainer, Piston Rod
.
4.........................1...........................14919...............................
Rod, Piston, Upper
.
5.........................2...........................13446...............................
End Plug Assy, White
.
.
.
13446-01.........................
End Plug Assy, White, HW
.
6.........................12.........................14241...............................
Spacer, 5600
.
.
.
14241-01.........................
Spacer, Hot Water
.
7.........................16.........................13242...............................
Seal, 5600
.
.
.
18759...............................
Seal, 5600 Low Drive Force
.
8.........................1...........................14920...............................
Rod, Piston, Lower, 9000
.
9.........................1...........................14905...............................
Piston, 9000
.
10.......................1...........................11710...............................
O-ring, -215
.
11........................1...........................12281...............................
O-ring, -338
.
12.......................1...........................11981-01..........................
Ring, Retaining
.
13.......................1...........................16098...............................
Washer, Nylon Brine
.
14.......................1...........................11973...............................
Spring, Brine Valve
.
15.......................1...........................13165...............................
Cap, Brine Valve
.
16.......................3...........................13302...............................
O-ring, -014
.
17.......................1...........................12550...............................
Quad Ring, -009
.
18.......................1...........................13167...............................
Spacer, Brine Valve
.
19.......................1...........................14925...............................
Brine Valve Stem, 9000
.
20.......................1...........................12626...............................
Seat, Brine Valve
.
21.......................1...........................15215...............................
Body, Injector, 9000
.
22.......................1...........................10914-X...........................
Injector Throat - Specify Size
.
23.......................1...........................10913-X...........................
Injector Nozzle - Specify Size
.
.
.
10225-X...........................
Injector Nozzle, SS
.
24.......................1...........................13303...............................
O-ring, -021
.
25.......................1...........................13166...............................
Cap, Injector, 5600
.
26.......................1...........................16595...............................
Spacer, 9000
.
27.......................1...........................13387...............................
Screw, Hex Hd Mach, 10-24 x 1 3/4
.
28.......................1...........................13361...............................
Spacer, 4650/9000
.
29.......................2...........................13301...............................
O-ring, -011, Injector
.
30.......................1...........................13497...............................
Disperser, Air, 5600
.
31.......................1...........................15348...............................
O-ring, -563
.
32.......................1...........................10227...............................
Screen, Injector
.
34.......................1...........................13244...............................
Adapter, BLFC
.
35.......................1...................................................................
Button, BLFC - Specify Size
.
36.......................1...........................13245...............................
Retainer, BLFC
.
.
.
12977...............................
O-ring, -015
.
38.......................1...................................................................
Button, DLFC - Specify Size
.
39.......................1...........................13173...............................
Retainer, DLFC Button
.
40.......................1...........................10332...............................
Fitting, Insert, 3/8
.
.
.
15415*.............................
Fitting, Insert, 1/2” Tube
.
41.......................1...........................10330...............................
Fitting, Sleeve, 3/8 Celcon
.
.
.
16124*.............................
Fitting, Sleeve, Delrin
.
42.......................1...........................10329...............................
Fitting, Tube, 3/8 Nut, Brass
.
.
.
16123*.............................
Nut, Brass
.
43.......................1...........................14928...............................
Plug, End Stub, 9000
.
44.......................1...........................14906...............................
Plate, End, 9000
.
45.......................4...........................15137...............................
Screw, Hex Wsh Mach 10-24 x 3/8
.
47.......................1...........................13387...............................
Screw, Hex Hd Mach, 10-24 x 1 3/4
.
.
.
13361...............................
Spacer, 4650/9000
.
48.......................1...........................13315...............................
Screw, Hex Wsh Hd, 10-24 x 1 3/16
Not Shown..........1...........................16140...............................Fitting, 1/2T x 1/4 NPT
NOTE:
For Hot Water delete items 41 & 42 and use 18698 (Nut, 3/8 Tube, w/Sleeve) and 15414 (Nut, 2900, w/Sleeve)
*These parts are used with #4 injector and 2 GPM or larger BLFC (Items 34, 35, and 36 are not used).
.
.
For Service Assembly Numbers, See the Back of this Manual
