Service Assemblies
AIR CHECK
60002-34 ................. AIR CHECK,#500,34” LONG
BRINE LINE FLOW CONTROLS (BLFC)
60022-12 ................. BLFC,.125 GPM,5000/5600/9000
60022-25 ................. BLFC,.25 GPM,5000/5600/9000
60022-50 ................. BLFC,.50 GPM,5000/5600/9000
60022-100 ............... BLFC,1.0 GPM,5000/5600/9000
60022-12 ................. BLFC,.125 GPM,5000/5600/9000
60022-25 ................. BLFC,.25 GPM,5000/5600/9000
60022-50 ................. BLFC,.50 GPM,5000/5600/9000
BRINE LINE FLOW CONTROL WASHERS
17307....................... WASHER,FLOW,.125 GPM
12094....................... WASHER,FLOW,.25 GPM
10759....................... LABEL,.5 GPM,1.5 LBS SALT/MIN
12097....................... WASHER,FLOW,1.0 GPM
BRINE VALVE
60032....................... BRINE VALVE,4600/5600
BYPASSES
60040SS .................. BYPASS VALVE,5600,3/4” NPT, BLK GRIP
................................. LEVER,STAINLESS STEEL
60041SS .................. BYPASS VALVE,5600,1” NPT, BLK GRIP
................................. LEVER,STAINLESS STEEL
60049....................... 3/4” BYPASS, PLASTIC
COLLECTORS, UPPER
18280....................... COLLECTOR,TOP,1” X .011,GRAY BAYONET
18280-01 ................. COLLECTOR,TOP,1” X .020,WHITE
................................. WIDE SLOT BAYONET
18280-02 ................. COLLECTOR,TOP,1” X .008,RED
................................. NARROW SLOT,BAYONET
COVER
18260-00 ................. COVER,FRONT,SMOKE
DISTRIBUTORS
60795-00 ................. DISTRIBUTOR ASSY,1”,STD, GRAY,.011,
................................. W/72”TUBE
60795-01 ................. DISTRIBUTOR ASSY,1”,WIDE, WHITE,
................................. .020,W/72”TUBE
60795-02 ................. DISTRIBUTOR ASSY,1” NARROW, RED
................................. .008, W/72” TUBE
DRAIN LINE FLOW CONTROLS
60705-XX ................ DRAIN LINE FLOW CONTROL
................................. (FROM .6 - 7.0 GPM)
60706-XX ................ DRAIN LINE FLOW CONTROL W/QUICK
................................. CONNECT (FROM 8-15 GPM)
60700-XX ................ DRAIN LINE FLOW CONTROL (8-15 GPM)
DRAIN LINE FLOW CONTROL WASHERS
19153....................... .06 GPM
19152....................... .08 GPM
19151....................... 1.0 GPM
12085....................... 1.2 GPM
19150....................... 1.3 GPM
12086....................... 1.5 GPM
19149....................... 1.7 GPM
12087....................... 2.0 GPM
12088....................... 2.4 GPM
12089....................... 3.0 GPM
12090....................... 3.5 GPM
12091....................... 4.0 GPM
19147....................... 4.5 GPM
12092....................... 5.0 GPM
17814....................... 6.0 GPM
12408....................... 7.0 GPM
17943....................... 8.0 GPM
17944....................... 9.0 GPM
16529....................... 10 GPM
16735....................... 12 GPM
16736....................... 15 GPM
FLOATS
60068-30 ................. FLOAT ASSY,2310,W/30” ROD
METER MODULE
60626....................... METER ASSY,TURBINE,ELECTRONIC, 3/4”
................................. WITH CLIPS AND SCREWS
19797....................... METER ASSY,3/4” DUAL PORT,SLP,
................................. ELEC,PLAS,TURB,W/O CLPS&SCRS
INJECTORS (1610)
18272-000 ............... #000 BROWN INJECTOR
18272-00 ................. #00 VIOLET INJECTOR
18272-0 ................... #0 RED INJECTOR
18272-1 ................... #1 WHITE INJECTOR
18272-2 ................... #2 BLUE INJECTOR
PISTON
60115-10 .................. PISTON ASSEMBLY
SAFETY BRINE VALVE
60014....................... 2310 PLASTIC
SALES & SERVICE AIDS
40734....................... SPEC SHEET
40272....................... SERVICE MANUAL
SEALS & SPACERS
60120....................... SEAL AND SPACER KIT
SERVICE EQUIPMENT
12763....................... STUFFER TOOL ASSY,5600/9000
12874....................... HOOK,SEAL
13061....................... PULLER ASSY,PORT RING
16174....................... SILICONE GREASE, 2 OZ. TUBE
16586-8 ................... SILICONE GREASE, 8 LB. PAIL
41891....................... WRENCH, PLASTIC BY-PASS
TIMER
42739....................... TIMER ASSY, SXT, PROFLO
YOKES
13708....................... 3/4” NPT
13708-10 ................. 3/4” BSP
13708NP .................. 3/4” NPT, NICKEL PLATED
13708-10NP ............ 3/4” BSP, NICKEL PLATED
13708-45 ................. 3/4” SWEAT
13708-45NP ............ 3/4” SWEAT, NICKEL PLATED
13708-40 ................. 1” SWEAT
13708-40NP ............ 1” SWEAT, NICKEL PLATED
13398....................... 1” NPT
13398-10 ................. 1” BSP
13398NP .................. 1” NPT, NICKEL PLATED
13398-10NP ............ 1” BSP, NICKEL PLATED
18706....................... 1” PLASTIC, MNPT
18706-10 ................. 1” PLASTIC, MBSP
18706-02 ................. 3/4” PLASTIC, MNPT
18706-12 ................. 3/4” PLASTIC, MBSP
19275....................... 3/4” 90 DEG ANGLE, NPT
19275-10 ................. 3/4” 90 DEG ANGLE, BSP
19275NP .................. 3/4” 90 DEG ANGLE, NPT, NICKEL PLATED
19275-10NP ............ 3/4” 90 DEG ANGLE, BSP, NICKEL PLATED
19275-45 ................. 3/4” 90 DEGANGLE SWEAT
19275-45NP ............ 3/4” 90 DEG ANGLE SWEAT, NICKEL PLATED
19620-01 ................. 90 DEG ADAPTER COUPLING
