Control Valve Assembly
For Service Assembly Numbers, See the Back of this Manual
Item No. Quantity Part No. Description
1 .......................1 ........................ 18815-20 .......................VALVE BODY ASSY,5000,W/MIXING
2 .......................1 ........................ 18264 ............................Spacer, End, 5000
3 .......................4 ........................ 14241 ............................Spacer, 5600
4 .......................5 ........................ 13242 ............................Seal, 5600
5 .......................1 ........................ 18266 ............................PISTON,5000,UPFLOW
6 .......................1 ........................ 14309 ............................Retainer, Piston Rod
7 .......................1 ........................ 18268 ............................End Plug Assy
8 .......................3 ........................ 18261 ............................Screw, Hex Wsh Hd, 10-24 x 13/16
9 .......................1 ........................ 18267 ............................Rod, Piston
10 .....................1 ........................ 17978 ............................Brine Valve Stem, 5600, Plastic
11 .....................1 ........................ 18755 ............................O-ring, Brine Seat
12 .....................1 ........................ 13167 ............................Spacer, Brine Valve
13 .....................1 ........................ 12550 ............................Quad Ring, -009
14 .....................2 ........................ 13302 ............................O Ring, -014
15 .....................1 ........................ 13165 ............................Cap, Brine Valve
16 .....................1 ........................ 11973 ............................Spring, Brine Valve
17 .....................1 ........................ 16098 ............................Washer, Nylon, Brine
18 .....................1 ........................ 11981-01 .......................Ring, Retaining
19 .....................1 ........................ 11183.............................O-Ring, -017
20 .....................1 ...............................................................Flow Washer (specify size)
21 .....................1 ........................ 11385-01 .......................Housing, Flow Control, Plastic
22 .....................1 ........................ 18312 ............................Retainer, Drain
23 .....................1 ........................ 13304 ............................O-Ring, -121
24 .....................1 ........................ 18303 ............................O-Ring, -336
25 .....................2 ........................ 10141 ............................O-Ring, -010
26 .....................1 ........................ 18276 ............................Plug, Injector
27 .....................2 ........................ 13771 ............................O-Ring, -012
28 .....................1 ........................ 18275-X ........................Throat, Injector (specify size) 000, 00, 0, 1, 2, 3
29 .....................1 ........................ 18274-X ........................Nozzle, Injector (specify size) 000, 00, 0, 1, 2, 3
30 .....................1 ........................ 18273 ............................Vortex, Generator
31 .....................1 ........................ 18271 ............................Screen, Injector, 5000
32 .....................1 ........................ 40064 ............................Seal, Injector, 4200
33 .....................1 ........................ 18278-20 .......................INJECTOR CAP ASSY,1610, REGULATED,5000,20 PSI,BLACK
.........................1 ........................ 18278-30 .......................INJECTOR CAP ASSY,1610, REGULATED,5000 30 PSI,GRAY
34 .....................2 ........................ 18262 ............................Screw, Hex Wsh Hd, 10-24 x 1
35 .....................1 ........................ 12977 ............................O-Ring, -015
36 .....................1 ........................ 13245 ............................Retainer, BLFC
37 .....................1 ...............................................................Flow Washer (specify size)
38 .....................1 ........................ 13244 ............................Adapter, BLFC
39 .....................1 ........................ 13308 ............................Fitting, Hose Barb, Black
.........................1 ........................ 12338 ............................Fitting, Elbow, 90 Deg, 1/2 Black
40 .....................1 ........................ 18280 ............................Collector, Top, 1” x .011 Gray Bayonet
.........................1 ........................ 18280-01 .......................Collector, Top, 1” x .020, White Wide Slot, Bayonet
.........................1 ........................ 18280-02 .......................Collector, Top, 1” x .008, Red Narow Slot, Bayonet
41 .....................1 ........................ 14613 ............................Flow Straightener
Filter Only (Not Shown)
.........................1 ........................ 13857 ............................Injector Plug Assy, w/O-ring
.........................1 ........................ 13918 ............................Plug, BLFC Module
.........................1 ........................ 18276-01 .......................INJECTOR ASSY,PLUG,W/O-RINGS
OPTION - Adapter Coupling Day Clock Only
45 .....................2 ........................ 19228 ............................Coupling, Adapter
46 .....................4 ........................ 13305 ............................O-Ring, -119
47 .....................2 ........................ 13255 ............................Clip, Mounting
48 .....................2 ........................ 13314 ............................Screw, Slot Ind Hex, 18-8 x .60
