Chapter 4 BIOS Setup Utility
78 Reference Manual XTX 820
The remaining fields listed below only appear if the BIOS detects additional USB mass storage
devices up to five more USB devices.
♦ Device #2 – [Mfg + model] or [USB2.0 device type]
♦ Emulation Type – [Auto], [Floppy], [Forced FDD], [Hard Disk], or [CDROM]
♦ Device #3 – [Mfg + model] or [USB2.0 device type]
♦ Emulation Type – [Auto], [Floppy], [Forced FDD], [Hard Disk], or [CDROM]
♦ Device #4 – [Mfg + model] or [USB2.0 device type]
♦ Emulation Type – [Auto], [Floppy], [Forced FDD], [Hard Disk], or [CDROM]
♦ Device #5 – [Mfg + model] or [USB2.0 device type]
♦ Emulation Type – [Auto], [Floppy], [Forced FDD], [Hard Disk], or [CDROM]
♦ Device #6 – [Mfg + model] or [USB2.0 device type]
♦ Emulation Type – [Auto], [Floppy], [Forced FDD], [Hard Disk], or [CDROM]
>Keyboard/Mouse Configuration
• Bootup Num-Lock – [Off] or [On]
This field enables or disables the Num-Lock (Number Lock) keypad, including the 10-key
numeric keys, to be turned on or off automatically when the system boots up. The field selection
will remain unchanged until the Num-Lock key on the keyboard is pressed to change the
Num-Lock state.
• Typematic Rate – [Slow] or [Fast]
• PS/2 Mouse Support – [Disabled], [Enabled], or [Auto]
∗ If [Disabled] is selected, the PS/2 Mouse will not have access to system resources and will
not be active after boot up.
∗ If [Enabled] is selected, the PS/2 Mouse can be used and will have access to system
resources after boot up.
∗ If [Auto] is selected, the BIOS will detect the PS/2 Mouse automatically, if present, during
the boot process. The PS/2 Mouse will have access to system resources and be active after
boot up.
>Remote Access Configuration (Serial Console or Console Redirection)
• Remote Access – [Disabled] or [Enabled]
This field enables Remote access (Serial Console or Console Redirection) through one of the
serial ports to a remote serial terminal. If this field is set to [Disabled], none of the supporting
features are listed on screen.
♦ Serial Port Number – [COM1] or [COM2]
Base Address, IRQ [3F8h, 4]
♦ Serial Port Mode – [115200, 8, n, 1], [57600, 8, n, 1], [38400, 8, n, 1], [19200, 8, n, 1], or
[09600, 8, n, 1],
∗ If [57600, 8, n, 1] is selected, the remote access operates at 57.6 kHz baud rate and there
are 8 start bits, no parity, and 1 stop bit used.
♦ Flow Control – [None], [Hardware], or [Software]
♦ Redirection After BIOS Post – [Disabled], [Boot Loader], or [Always]
∗ If this field is set to [Disabled], the Serial Redirection function is disabled at the end of
BIOS POST.
