7
4. Profibus
Profibus is standardized according to DIN 19 245.
We support the following features:
Get OV (long)
Read
Write.
FMS features supported are therefore:
80 30 00 00 00 00
Our equipment is slave.
We provide the following communication references:
Index Typ SAP
2 MSZY 3
3 MSAZ 4
4 MSZY 5
5 MSAZ 6
6 MSZY 7
7 MSAZ 8
8 MSZY 9
9 MSAZ 10
(Master Slave Cyclic / Acyclic)
4.1 List of the objects for the Digital Industrial Controller Type 1110
Structure of the masks
Within a mask, the variable required for the configuration from among the following will
be represented. Sequence: 1st variable = LSB
LSB represented.
1-
is required in the configuration
0- is not required in the configuration
20 UINT16 Mask process values
21 UINT8 Hardware unit
22 FLP X1 measurable value channel 1
23 FLP X2 measurable value channel 2
24 FLP W1 set point main controller or single controller
25 FLP Yh correcting variable main controller at cascade
26 FLP W2 set point support controller at cascade
27 FLP Y2h correcting variable heating/continuous
28 FLP Y2k correcting variable cooling
29 FLP Xdh control offset main controller
