5
3 System description
3.1 Introduction
The Digital Industrial Controller 1110 as well as the Digital Batch Controller 1115 can be
equipped with a digital interface.
Using the additional card required for this purpose, either a point-to-point connection can
be erected through RS 232 or, by using additional equipment, a network can be built
through
RS 485/Profibus.
3.2 Switch configuration
ON
1 2 3 4 5 6 7 8
RS 232 RS 485 RS 485 Profibus Profibus
add. equipment add. equipment
1 OFF OFF ON OFF ON
2 OFF OFF ON OFF ON
3 OFF ON ON ON ON
4 OFF ON ON ON ON
5 ON OFF OFF OFF OFF
6 ON OFF OFF OFF OFF
7 OFF ON ON ON ON
8 OFF OFF OFF ON ON
