12
80 UINT16 Mask configuration alarm function
81 FLP X1- lower alarm limit actual value
82 FLP X1+ upper alarm limit actual value
83 FLP A1 Hy alarm hysteresis actual value
84 FLP A1Q- lower alarm limit absolute value ratio regulation
85 FLP A1Q+ upper alarm limit absolute value ratio regulation
86 FLP A1QH hysteresis absolute value ratio regulation
87 UINT8 Mode alarm function
0: absolute alarm
1: band alarm
90 UINT16 Mask configuration set point limits
91 FLP W1u lowest set point limit
92 FLP W1o upper set point limit
100 UINT16 Mask configuration set point ramp
102 FLP D gradient (standard: W/min)
103 UINT8 Pon ramp at alteration of set point
0:
o f f
1: on
110 UINT16 Mask configuration Set Point Tracking
111 FLP SPTE final value set point tracking (read only!)
112 FLP SPTD gradient set point tracking
113 UINT8 SPT on / off
0: o f f
1: on
120 UINT16 Mask configuration disturbance-variable compensation
121 FLP kps amplification
122 FLP Tds derivative-action time
123 FLP Ts delay time
124 FLP Xsd insensitiveness
125 FLP X0 operating point
140 UINT16 Mask configuration main controller
141 FLP kp1 amplification
142 FLP Tn reset time
143 FLP Tv derivative-action time
144 FLP Ratio derivative-action time / delay time
145 FLP Y0 operating point
146 FLP Xtb insensitiveness
