Section 1 Introduction Installation and Operation Manual
X-VA-MT3600-eng
Part Number: 541B075AAG
February, 2011
Models MT3600, MT3601 & MT3602
1-1 Description
The Brooks ® MT3600, MT3601 and MT3602 armored flowmeters are
designed to be reliable and economical high flow rate purge meters with
10% full scale accuracy. These meters are especially useful for metering
coolants, pump seal fluids, lubricants under pressure, and opaque fluids.
The flow rate is measured by the movement of a tapered plug in a fixed
orifice. Indication is by an external tubular follower coupled magnetically to
an extension of the tapered plug. A certified explosion-proof/intrinsically
safe alarm is optional.
1-2 Design Features
•
• Flanged, NPT or socket-welded connections
• 10% full scale accuracy
• Disassembly for cleaning without removal from the line
• Standard direct reading, detachable scales
• Permanent magnetic link between metering float and indicator/alarm
• CSA certified explosion-proof/intrinsically safe alarm
1-3 Specifications
•
Capacities and Pressure Drops
Refer to Table 1-1
Accuracy
Standard Flow Accuracy: ±10% Full Scale from 100% to 10% of scale
reading
Optional Flow Accuracy: ±5% accuracy
Repeatability
1.0% Full Scale
Pressure Ratings
Refer to Table 1-2 for maximum non-shock pressure
Scales
Standard: Detachable aluminum plate
Length: 1.5 inches (38 mm)
Graduations: Choice of direct reading units, millimeter or percentage of
maximum flow with factor tag
Optional: Dual scales
