1-5
Section 1 Introduction Installation and Operation Manual
X-VA-MT3600-eng
Part Number: 541B075AAG
February, 2011
Models MT3600, MT3601 & MT3602
Alarm Altitude
2,000 meters
Alarm Humidity
50 - 80% Relative Humidity
Pollution Degree
2 Degrees
Installation
Category II
Ambient Operating Temperature
-20°F to 122°F (-29°C to 50°C)
Operating Fluid Temperature Limits
-20°F to 250°F (-29°C to 121°C)
Alarm Dimensions and Wiring Diagrams
Dimensions: Figures 1-2, 1-5 and 1-6
Wiring Diagrams: Figures 1-7, 1-8 and 1-9
Control Drawing: Figure 1-10
Switch Isolater: Figure 1-11
Reed Switches Only: For intrinsically safe applications, remotely mounted,
switch isolator/power supplies are available in single channel or dual
channel configuration with 220 or 120 Vac Volt supply options. Output is
via SPDT relays rated at 250 Vac, 4A, 24 Vdc, 4A. Refer to Figure 1-11.
CONTROL VALVES
Model MT 3602: Size 8 only, 316 stainless steel material only- on inlet or
outlet.
Dimensions: Figures 1-3, 1-4, 1-5 and 1-6
Minimum/maximum operating temperature: -20°F (-29°C) to 400°F
(204°C)
Cv factor: 1.2
MATERIALS OF CONSTRUCTION:
316 stainless steel body and stem, Kel-f seat, Teflon packing.
FLOW CONTROLLERS
Model MT 3602: Size 8 only, 316 stainless steel material only- on inlet or
outlet.
Refer to DS-VA-FC-eng for Flow Controller information
Flow controllers can be supplied integrally mounted to the inlet or outlet of
the instrument. For the flow controller's complete instruction manual go to
our website: BrooksInstrument.com, select Documentation, Precision
Valves & Flow Controllers, select FC8800, or FC8900.
