Emtek Keypad Deadbolt Locksets User Manual
Page 5
5
3. Install Outside Trim Plate Assembly
4. Install Inside Chassis
Position the Outside Trim Plate Assembly through the bore hole.
!
Flat Shaft
through latch.
Flat Shaft must be
in vertical position
for installation.
ONCE POSITIONED,
OUTSIDE TRIM PLATE
ASSEMBLY REQUIRES
SUPPORT.
Feed wire harness
through the bore hole.
HOLE FOR FLAT
SHAFT MUST BE IN
VERTICAL POSITION
FOR INSTALLATION.
!
Step 1: Confirm the position of Flat Shaft.
√ Correct for Installation.
X Incorrect for Installation.
