Emtek Double Cylinder Deadbolt User Manual
Installation guide, Double cylinder deadbolts
2 3/8” or 2 3/4”
Backset
2 1/8” Diameter
Bore
1/8” Deep
2 1/4”
1 “
1” Diameter
Edge Bore
1. Door Prep
2. Door Jamb Prep
3. Install Latch
Crosshairs
at bottom.
Installation Guide -
Double Cylinder Deadbolts
4. Outside Installation
Install Deadbolt on regular door.
Install Deadbolt on regular door.
Install Deadbolt on thin door. Extension Collar is provided for the following products:
8355, 8364
5. Inside Installation
Door Thickness: 1 3/8” - 1 3/4”
Door Thickness: 1 3/8” - 1 3/4”
Door Thickness: 1 3/4” - 2 3/4”
Door Thickness: 1 3/4” - 2 3/4”
Extension Collar
Extension Collar
2-3/4"
3/16” Deep
2 3/4”
1 1/8”
3/4”
11/4”
11/4” From
Door Face
IN4- DEADBLTDUBL 04-25-2011
Tail Piece Horizontal
Tail Piece Horizontal
Tail Piece Vertical
Tail Piece Vertical
