7 8
Finding the Camera’s IP Address
4. FINDING THE CAMERA’S IP ADDRESS
Use the steps below to find the camera’s IP address and connect to the
camera over the local area network (LAN) using NVMS, UPnP on
Windows® 7, or Bonjour® in Mac OS®.
4.1 Finding the Camera’s IP Address Using NVMS
1. Install NVMS from the CD. Now Double-click the NVMS icon ( ) on the
Desktop. The log in screen appears.
2. Under User Name and Password, enter the default NVMS user name
( admin) and password (admin). Click Login.
Enter Admin
Enter Admin
Click Login
3. NVMS opens and scans the local network for connected cameras.
Detected camera IP addresses on the LAN appear in the Device List on
the left side of the screen with a icon.
Found camera
IP address
Finding the Camera’s IP Address
3. Connect the cable of power supply.
4. Loosen the bracket locking ring to adjust the camera position.
5. Lock into place, remove underside adjust the focus / zoom.
a. Fixed Lens model has not focus/zoom adjustment.
Loosen Tighten
Locking screw
