7 8
Finding the Address
4. FINDING THE CAMERA’S IP ADDRESS
Use the steps below to find the camera’s IP address and connect to the
camera over the local area network (LAN) using NVMS, UPnP on
Windows® 7, or Bonjour® in Mac OS®.
4.1 Finding the Camera’s IP Address Using NVMS
1. Install NVMS from the CD. Now Double-click the NVMS icon ( ) on the
Desktop. The log in screen appears.
2. Under User Name and Password, enter the default NVMS user name
( admin) and password (admin). Click Login.
Enter Admin
Enter Admin
Click Login
3. NVMS opens and scans the local network for connected cameras.
Detected camera IP addresses on the LAN appear in the Device List on
the left side of the screen with a
icon.
Found camera
IP address
6. If you need to adjust the
viewing angle, loosen the 6
screws on the sides of the
ball camera and adjust the
ball camera. Do not remove
the screws holding the ball
camera. Tighten the screws
when finished.
NOTE: Ensure the ball
camerais pointedinthesame
direction as the IR LED to
ensure a good nighttime
image. Loosen screws to adjust the
angle of the ball camera
IR LED
Do not remove the screws
holding the ball camera.
7. Ensure the rubber gasket
inside the camera is
7
properly in place, then
replace the camera cover
and the camera cover
screws (2x).
