14
TV monitor to view
video.
AC 24V/ DC 12V Power port z Power port.
z Input 12V DC or
AC 24V
Red light z System boot up-
red light is on
z System
upgrades-red light
flashes
z System resets-
red light flashes.
Green light z Normal working
status-green light
is on.
z Display record
status: Record-
green light
flashes.
STATUS
Indication Light
Yellow light z Detect the
wireless device-
yellow light is on.
3G Connect to 3G card.
Please note it is for
3G series product
only.
WIFI Antenna port Connect to 3G/WIFI
antenna to receive the
wireless signal.
Please note this
function is for some
series products only.
IN Alarm input port I/O port Alarm input port 1. To
receive the signal from
