5

GND

Please make sure the

device is securely

earthed to prevent the

thunderstorm strike.

1.2 Side Panel

Please refer to the following interface for side panel dimension information. The unit is mm. See

Figure 1-2.

Figure 1-2

1.3 Front Panel

Please refer to the following interface for the front panel information. The unit is mm. See Figure

1-3.
