CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning with an arrowhead symbol, within an equilateral triangle
is intended to alert the users to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point with an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
This equipment has been tested and found to comply with limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy, if not
installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the
interference at his own expense.
Changes or modifications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.
To prevent electric shock and risk of fire hazards:
• Do NOT use power sources other than that specified.
• Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service
person and should conform to all local codes.
Guide
Solution General Specifications
General
Power source Regulated DC 12V
Power consumption 60mA for APS Module / (With IR LED ON 220mA Typical)
IR LED consumption 170mA 10pc Super Flux IR LED
Scanning system 2:1 interlace
Scanning frequency 15.734KHz(H), 59.95Hz(V)
Effective Pixels 756(H) x 504(V)
Resolution 700TVL
E-Shuter PAL: 1/25~15000s ; NTSC: 1/30~15000s
ACG / BLC On
WB AWB
Sync System Internal
Min.illumination 0 Lux IR LED On
Video output 1.0 Vp-p (75 ohm, composite)
S/N Ratio more than 47dB (AGC OFF)
Video output BNC Connector
Lens mount Fixed mount
Lens Varifocal 2.8-12 mm or Fixed Lens models 3.6mm
Operating temperature -10°C ~ +50°C / -40°F ~ 122°F
Operating humidity 0-90% (non-condensing)
Model Features:
• APS+ Technology
• 700TVL 1/3”
• Ultra Low Power
• No Complex OSD
• BNC Video Output
• Standard 12VDC Operation
• IR LED Models for Day/Night Operation
• True Day/Nigh ICR (ie LED Models)
*Specifications subjected to change without prior notice.
