14

9620 Professional OBD II Scan Tool

SelectCustom List

«ABSLT TPS(%)

]

`«CALC LOAD(%)

[

COOLANT(oF)

View Instructions

For Creating Custom

Data List?

YES

ABSLT TPS(%)

0.0

CALC LOAD(%)

5.3

ENGINE(RPM)($10)

180[

ENGINE(RPM)($1A)

865

SelectDisplay Line

2 Lines

]

3 Lines

`4 Lines(Default)

— Entire Data List

Select Entire Data List to display all PIDs supported by vehicle under test.

— Custom Data List

To display only certain PIDs, select Custom Data

List. The ability to display certain PIDs helps in

diagnosing a specific driveability symptom or

system.

If choosing to view a Custom Data List, the scan

tool asks if help is needed to view the

instructions. Select desired response and press

ENTER.

• Use UP/DOWN arrow keys to move

cursor up and down through list.

• Use RIGHT arrow key to select or deselect

PIDs. Selected PIDs are marked with «

symbol.

• Use LEFT arrow key to deselect all

marked PIDs.

• Use the ENTER key to link to the vehicle and retrieve the marked PIDs.

When finished selecting PIDs, press ENTER key to begin viewing them.

NOTE: Refer to Appendix A for a complete list of PIDs.

— View Data Setup

View Data Setup allows display of PIDs on one,

two, three or four lines. Selecting fewer lines of

data provides faster update speeds. The scan

tool default is four-line display.

When scan tool links to vehicle, PIDs will display. Navigate through PID list with following

keys:

• Press UP/DOWN arrow keys to scroll Up/

Down line-by-line through list.

• Press LEFT/RIGHT arrow keys to Page

Up/Page Down.

• Press BACK key to return to Select Data

To View menu.

The same parameter may appear twice if vehicle is equipped with more than one computer

module — Powertrain Control Module (PCM), Transmission Control Module (TCM), etc. The

scan tool identifies them by identification names (ID) assigned by manufacturer (i.e. $10,

$1A, etc). The computer module ID blinks in parentheses. If one or more modules stops

responding, the scan tool displays a message that the module is not responding and asks to

continue without it. If NO is selected, scan tool attempts to reestablish communication with

that module.

SelectData To View

Entire Data List

`Custom Data List

View Data Setup

9620 Professional OBD II Scan Tool

23

Enter Code: P0100 |

Use Arrow Key ^

To Change Or Press

ENTER To Accept

P0A08

DC/DC Converter

]

Status Circuit

[

OBDII Function List

|

13)Review Data

]

14)PrintData

`15)Code Lookup

Enter Code: P0A08 |

Use Arrow Key

^

To Change Or Press

ENTER To Accept

P1100

Manufacture Contrl

]

[

Fuel Air Metering

3.2 Code Lookup

Code Lookup is used to look up definitions of Diagnostic Trouble Codes (DTCs) stored

in the scan tool. The scan tool does not require power from the vehicle to perform this

function. Internal battery power can be used.
To look up DTC definitions, select Code Lookup

from the OBDII Function List and press ENTER.

NOTE: When entering codes, only one character can be changed at a time.

To enter a code:

• Use the LEFT/RIGHT arrow keys to move

the ^ symbol under the character that

needs to be changed. The cursor moves

to the right and wraps around to the

beginning when the end is reached.

• Use the UP/DOWN arrow keys to change

the selected character.

• Press the ENTER key to display the

definition.

After entering the code and pressing ENTER,

the code and definition display.

If the DTC is manufacturer specific or does not

exist for the vehicle, some information can be

determined based on the range of the DTC (see

page 24)

In the definition screen, pressing the ([) or (]) arrow key increments/decrements the

code and its definition. Undefined codes are skipped.
Press the BACK key to return to the Enter Code screen. Press the BACK key again to

return to the OBDII Function List.

NOTE: Refer to an appropriate vehicle service manual for manufacturer specific codes.
