Configurable HMI Panel
Installation Guide and User Manual
Page 4 / 16
Specifications
Front Panel
Overall Size: 14” x 7”/355.6 mm x
177.8 mm
Material: Polyester PVS-G on Aluminum
Printing: 2 colors, printed on the reverse
Embossing: All keys embossed
EasyLabel: Several EasyLabel slide-in
pockets for individual labeling of keys
Display Window
Visible Size: 4.65” x 3.52”/118.2 mm x
89.4 mm
Material: Acrylic glass S000
Thickness: 0.08”/2.0 mm
Coating: Non-reflexing, A1
Keys
Number: 43 keys
Operations: 1 million operations/key
Pressure/key: 3 N per key on contact
spring
Material: Gold on silver polymer
Resistive Touchscreen (optional)
Size: 5.7”
Type: DMC AST 057, resistive
Connector: USB
Controller: Integrated
Electrical Specifications
Voltage: 5V
Connector: USB (cable included)
EMC shielding: None
LED’s: 10 LED’s, yellow
User specified for auxiliary discrete
pushbuttons and indicators
Mechanical Specifications
Material: Aluminum
Thickness: 0.12”/3.0 mm
Surface: Natural anodized
Mounting: 6 stud bolts FH-832-10 (UNC
thread)
Emergency Stop Switch
Actuator: Maintained with twist-to-release
Contact: 1NO/1NC SM contact,
solder/plug-in terminals
Max rating: 3A/250VAC
Front protection: IP 65 as per EN IEC
60529
This device complies with:
EN IEC 60947-5-1, EN IEC 60947-5-5,
and ISO 13850
Keylock
Actuator: Flush mount 2 position
maintained,
Key: Removable in “A” position
Contact: 1NO/1NC SA contact,
solder/plug-in terminals
Max rating: 5A/250VAC
Front protection: IP 65
Mechanical life: 50,000 cycles of
operations
Illuminated Pushbuttons
Actuator: Flush momentary action
Contact: 1NO, Max rating: 100mA/42V
Front protection: IP 65
Mechanical lifetime: > 1 million cycles of
operations
Animation sequence:
Customer defined; illumination created by
8 SMT LEDs
