Configurable HMI Panel
Installation Guide and User Manual
Page 3 / 16
Overview of variants
EAO offers 4 variations of the C-HMI Panel:
EUS-C-HMI-06-AGL-EK8 – 5.7” window, acrylic glass lens, no display, E-Stop, keylock, 8
discrete pushbuttons
EUS-C-HMI-06-AGLD-EK8 – 5.7” window, acrylic glass lens, with display, E-Stop, keylock, 8
discrete pushbuttons
EUS-C-HMI-06-RTS-EK8 – 5.7” window, acrylic glass lens, resistive touch screen, no
display, E-Stop, keylock, 8 discrete pushbuttons
EUS-C-HMI-06-RTSD-EK8 – 5.7” window, acrylic glass lens, resistive touch screen, with
display, E-Stop, keylock, 8 discrete pushbuttons
The approved Sharp display for the C-HMI Panel is: LQ057Q3DC12
QVGA/320*240, CCFT backlight
EAO #
Touch screen
Keyboard Interface
1
Touch
screen
Interface
2
EUS-C-HMI-06-AGL-EK8
-
USB / RS232
EUS-C-HMI-06-AGLD-EK8
-
USB / RS232
EUS-C-HMI-06-RTS-EK8
5.7"
USB / RS232
USB / RS232
EUS-C-HMI-06-RTSD-EK8
5.7"
USB / RS232
USB / RS232
Table 1: Product Variation Interfaces
1
The keyboard interface is set up via a DIP switch (see section “Keyboard Interface settings”)
2
The touch screen interface is set up via jumpers (see section “Touch Screen Interface settings”)
