VMP SERIES OF PRINTERS USER'S GUIDE

6

Loading Paper

1. Open the printer’s cover to the fully open position.
2. Orient the printer so that you can access the locking

lever.

3. Depress the locking lever to open the print

mechanism (Figure 8).

4. Verify the center guide is centered (Figure 9).
5. Lift the two tractor feed clips (Figure 10).

Note: Do not use paper that has glued edges or paper

with carbon between the sheets; only use paper with

clawed crimps.

Locking lever

Figure 8

Figure 9

Center

guide

Figure 10
