Datamax-O'Neil MP Compact4 Mark II Cutter Option User Manual
Page 2
1
Overview
This document describes the contents, installation, and use of the Cutter option for the MP Compact
printers. After verifying the contents of the kit and the tools needed, follow the steps below to install and
begin using the option.
CAUTION
For your safety and to avoid equipment damage, always turn ‘Off’ power and unplug the
printer’s power cord before beginning this installation and when performing service.
Contents of the Cutter Kit
This kit contains the following item:
• 1 x Cutter Unit
• 1 x Screws (PZ M3x10)
• 1 x Washer
• 3 x Screws (MRX M3x12)
• 4 x Screws (K6S M5x14)
Tools
Required
To install this option, you will need
• Allen Key, 3mm
• Phillips
Screwdriver
