MICROFLASH 4TE PRINTER USER'S GUIDE
1
microFlash 4Te Printer: Closed View
microFlash 4Te Printer: Open View
Power LED
Radio LED
Charge/Battery LED
Figure 1
LEDs
Figure 2
Roller
Paper Cavity
Power Port 1
Battery Retaining
Clip
Media Function
Button
Charge LED
Print Head
Release Lever
Data Port
Figure 3
Radio LED
Power LED
Battery/
Battery Well
Battery
Retaining Clip
