MICROFLASH 4T PRINTER USER'S GUIDE
5
Installing Paper
1. Insert a roll of paper with the end of the roll exiting
from the bottom of the paper cavity (Figure 4).
2. Open the print head by raising the gray, print head
release lever until it is fully open. Do not stop at the
partial open position (Figure 5).
3. Wake up the printer by briefly pressing the red, self-
test button (Figure 6).
4. Feed the end of the paper under the roller. The
paper automatically feeds under the roller and exits
the top of the print head. Verify the paper exits the
print head straight (Figure 7).
Figure 4 Figure 5
Figure 6 Figure 7
