4
Encoded RFID data can also be exported to a host device by enabling OPTION FEEDBACK. This data is
contained in the format [CR] where:
A - Is the device type: R = RFID; and, S = Linear Scanner.
B - Is the resulting status: C = label complete; F = faulted (failed) label; and, U = unknown.
C - Is the number of expected reads for bar codes or tags, given in two characters.
D - Is the number of good reads for bar codes or tags, given in two characters.
E - Is the printer’s internal Job and Sub Job Identifier, given in four characters each.
F - Is the data that was read, delimited with semicolons (;) on multiple reads.
Proceed as follows to capture RFID data:
Step Instruction Display
1 Press MENU.


2 Scroll to COMMUNICATIONS and press ENTER.


3 Scroll to HOST SETTINGS and press ENTER.


4 Scroll to OPTION FEEDBACK and press ENTER.


5
Select the output format (RFID HEX or RFID ASCII) and press ENTER. 

6
Press ESC; and, at the SAVE CHANGES prompt, press ENTER to
complete the setup.



Notes: (1) For menu system details, see the Operator’s Manual.
(2) Bidirectional communications must also be enabled, and an appropriate cable attached.
