NAME
BAR CODE TYPE RATIO VALID CHARS COMMENTS
BCI25 Interleaved 2 of 5 2:1 0-9 Needs an even number of digits – if not
even, a leading zero is inserted
BC128 Code 128 2:1 All lower case, upper case,
punctuation, numbers, and
control codes in ASCII 0x00
through 0x7F Escape Easy Print “|” (end of data) with
leading “/”; to print “/” use “//”. Function
characters 1-4 are /1 - /4
EN128 EAN-128 2:1 All lower case, upper case,
punctuation, numbers, and
control codes in ASCII 0x00
through 0x7F Escape Easy Print “|” (end of data) with
leading “/”; to print “/” use “//”. Function
characters 1-4 are /1 - /4
BC39N Code 39 2:1 Space $ % + - . / 0-9 A-Z Printer inserts leading and trailing “*” if
not sent in data
BC39W Code 39 3:1 Space $ % + - . / 0-9 A-Z Printer inserts leading and trailing “*” if
not sent in data
COBAR Codabar 2:1 $ + - . / 0-9 ABCD Guard bars are sent as part of data
I2OF5 Interleaved 2 of 5 2.5:1 0-9 Needs an even number of digits – if not
even, a leading zero is inserted
EAN08 8 Digit EAN 2:1 0-9 Send 7 digits – printer calcs chksum (8 th
char)
EAN13 13 Digit EAN 2:1 0-9 Send 12 digits – printer calcs chksum
(13
th
char)
UPC-A UPC A 2:1 0-9 Send 11 digits – printer calcs chksum
(12
th char)
UPC-E UPC E 2:1 0-9 Send 7 digits – printer calcs chksum (8
th
char)
PD417 PDF-417 Set by
User
Any byte value 0-255 Text and Binary modes supported.
Large numeric sequences are not
compressed to the maximum extent, but
will print
BC093 Code 93 2:1 All lower case, upper case,
punctuation, numbers, and
control codes in ASCII 0x00
through 0x7F. Some are
combinations (e.g. A=A but
a=+A) Printer calculates check digits
