Test an Diagnostics
 Input Monitor – Display incoming GPIO binary signal states using the
DIAGNOSTICS  OPTIONS TESTING  TEST GPIO  MONITOR GPIO INPUT
selection.
SOP FEED PAUSE REPRT
1 1 1 1
 Note: Unused, non-connected inputs will have an indeterminate state, and may
assume a value of 1 or 0.
 Output Monitor – Display outgoing GPIO binary signal states using the
DIAGNOSTICS  OPTIONS TESTING  TEST GPIO  TEST GPIO OUTPUT
selection.
 Note: Unused, non-connected outputs will have an indeterminate state, and may
assume a value of 1 or 0.
 GPIO Report – Print the configuration and current signal state information using the
DIAGNOSTICS  OPTIONS TESTING  TEST GPIO  PRINT SIGNAL INFO
selection:
GPIO SIGNAL INFO
WED 11:04AM 4JUL2011
CARD ID#3
OUTPUT SIGNALS
END OF PRINT
PIN# 11 GPIO A
LOW PULSE
CURRENT LEVEL 1
RIBBON LOW
PIN# 9 GPIO A
ACTIVE LOW
CURRENT LEVEL 0
SERVICE REQUIRED
PIN# 10 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
MEDIA OUT
PIN# 12 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
RIBBON OUT
PIN# 13 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
DATA READY
PIN# 14 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
OPTION FAULT
PIN# 15 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
INPUT SIGNALS
START OF PRINT
PIN# 3 GPIO A
ACTIVE HIGH
CURRENT LEVEL 1
FEED
PIN# 4 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
TOGGLE PAUSE
PIN# 5 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
REPRINT
PIN# 6 GPIO A
ACTIVE LOW
CURRENT LEVEL 1
EP RL SR MO RO DR OF
1 1 1 1 0 1 0
