4
1.2.2 Charging the Battery
 Plug the battery charger adapter output cable into the battery charger connector as shown
in Figure 3.
FIGURE 3: CHARGING THE BATTERY CARTRIDGE
 Plug the battery charger adapter into the appropriate AC line voltage socket.
 The Yellow/Amber charging LED will illuminate indicating that the battery is charging.
 The battery will be fast charged and, after approx. 180 minutes, the LED will turn off.
 To remove the battery cartridge, open the battery door and tip the battery out of the
printer
.
Note: To ensure a full charge do not operate the printer while charging.
Note: The wall mounted charger is Class II equipment ( ) . Multiple plug configurations
comply with most international standards. The wall mounted charger is not supplied with
plugs for use in Korea.
 The wall mounted charger has the following specifications:
Model APEX 3
Input Voltage/Current 100-240 VAC/0.55A
Input Frequency 50-60 Hz
Output Voltage/Current ( ) 10VDC/2.4A
Do not use a charger not approved by Datamax-O’Neil for use with the APEX 3. Use of
an unapproved charger could damage the battery pack or the printer and will void the
warranty.
The battery terminals are well recessed inside the printer. Do not allow them to contact
conductive material since this may create a short circuit which could cause injury or
start a fire.
