Data Connection
Datamax-O’Neil MF8i Installation Guide
Data Connection
The MF8i has an RS232 data connection. If you choose to cable connect your computer or
handheld device to the printer, Datamax-O’Neil sells many standard cables to connect to the
MF8i printer. Contact Datamax-O’Neil for the latest cable list.
If you choose to install your own cabling, see the diagram below for cable pin outs and
design.
RJ-11 Data Connector
RJ-11 Plug Mating Connector
