Reference Level
The Inclinometer has a mounting reference angel (black line)for an optimal mounting of the inclinometer,
which is parallel to the x-axis. This reference angle must be placed exactly parallel to the object to be
measured to prevent or minimize any mechanical offset/cross sensitivity.
Reference angle of the inclinometer, top view.
Y
X
Reference angle
