BEI Sensors Heavy Duty Inclinometers User Manual
BEI Sensors Tools

HEA VY DUT Y INCLI NO ME T E R
ANA LOG & RS 232 I NT ER F ACE
The Heavy Duty inclinometers are robust inclination sensors specially designed for applications involving
rough handling and exposure to rigorous conditions. The die cast aluminium housing and the metal
connector enhance the mechanical strength of the sensor and make it ideal for heavy duty usage.
Main Features
−
Dual Axis Inclinometer ± 80°
−
Single Axis Inclinometer 360°
−
High Resolution: 0.01°
−
Accuracy: 0.1°
−
Die-cast Aluminium Alloy Housing
−
Digital Interface: RS232, Code ASCII
−
Analog Interface: Voltage, Current
−
High Protection Class: IP 69K, IP68, IP67
Electrical Features
−
Highly Integrated Circuit in SMD-
Technology
−
Polarity Inversion Protection
−
Over-Voltage-Peak Protection
Programmable Parameters
−
Preset
−
Baud Rate
−
Software Filters
−
Resolution
−
Analog Teach-in
Applications
−
Measurement of Inclinations and Rotational
Movements
−
Construction Machines
−
Cranes
−
Mobile Platforms
−
Marine & Offshore Machinery
