Page 4 Analog Industrial Data Sheet Version: 20130503
INDUST RIAL I NCLI NOME T ER
ANA LOG & RS 232 I NT ER F ACE
Programmable Parameters
The parameters of inclinometer can be re-configured using the RS232 interface . Additionally Preset can
also be done through a (soon to be available) Analog Teach-in. (Refer to User Manual for additional
information.)
Modes of Operation Inclinometer can be switched between Polled Mode or
Continuous mode.
Baud rate The Baud rate can be programmed to lie between ranges of
2400 Baud and 115200 Baud.
Output Transmission Rate The transmission rate of angular values can be adjusted to lie
between 62.5ms and 10 seconds per value.
Moving Average Filter Used to calculate the output position value as an average over
last N values where N varies from 2 to 256 measurements in
steps of N = n², n = 1, 2, 3 …
Preset Value The current position value is set to the mid angle position by the
parameter preset.
