Page 2 Analog Industrial Data Sheet Version: 20130503
INDUST RIAL I NCLI NOME T ER
ANA LOG & RS 232 I NT ER F ACE
Technical Data
Electrical Data
Model INC -080 INC -360
Measurement Range ± 80° 360°
Number of Axes 2 1
Analog Interface Voltage 0.5 to 4.5 V, 0° = 2.5 V
Load ≥ 10 KΩ with 12 V DC 0.5 to 4.5 V, 0° = 0.5 V
Load ≥ 10 KΩ with 12 V DC
Current 4 mA to 20 mA , 0° = 12 mA
Load ≤ 270 Ω
1
4 mA to 20 mA , 0° = 4 mA
Load ≤ 270 Ω
1
Digital Interface RS232 (ASCII Format)
Baud Rate Max. 115200 Baud (Programmable)
Resolution 0.01°
Accuracy (T = -10 °C to +40 °C)
2
0.1°
Sensor Response Time 10 ms (Without Filter)
Recommended Measurement
Rate
Up to 10 Hz
Supply Voltage
3
10 to 30 V DC (Absolute Maximum Ratings)
Power Consumption
≤
0.7 W
EMC Emitted Interference: EN 61000-6-4
Noise Immunity: EN 61000-6-2
Connection Connector Output, 8 Pin M12 male (A-coded)
Mechanical Data
Housing Material Glass Fiber Reinforced PBT (Polybutylene Terephthalate)
Potting Material PUR (Polyurethane)
Shock (EN 60068-2-27) 2 
100 g (half sine, 6 ms)
Vibration (EN 60068-2-6)
2
1.5mm (10 to 58 Hz) &

20 g (58 to 2000 Hz)
Weight 75 gm / 3 oz
1 R
L
< 500 Ω with 15 V DC
2
Further data available on request
3
Inclinometers should be connected only to subsequent electronics whose power supplies comply with
EN 50178 (Protective Low Voltage)
