5
IN STALLATIO N & R EPAIR G U ID E
Split W all-M ounted air conditioner
O uter diam eter of
copper pipe
Tightening torque
6.35(1/4")
9.52(3/8")
12.7(1/2")
15.88(5/8")
19.05(3/4")
Table 1 Torque based upon the w rench to be used
In case of the users purchasing the m achine for quick
coupler,there is no need to do the air purging procedures
and the follow ing pipeline connection procedures should
be adopted:
1.R em ove the dust caps from the indoor and outdoor units,
and the connecting pipe.
2.Align the joint counter of connecting pipe w ith the proper
i ndoor and outdoor j oi nt coni c surfaces,ti ghten the connecti ng
nut m anually.Then,m ake it secure w ith a w rench as show n
Fig. 6 ,applying to above torque Table 1.
3.R em ove the tw o valve core caps from the outdoor unit.
4.Turn on the high and low pressure valve cores w ith an
socket w rench,then tighten the tw o valve core caps of the
outdoor unit (Fig.7).
5.Finally ,w rap the hot insulating cotton around the joints
of indoor and outdoor units.
1.C onnecting pipe bending m inim um radius param eters
(Table 2)
2.Q uick coupler assem bly and disassem bly lim it:
the assem bly and disassem bly tim es are inadvisably
m ore than 7.
*N otes on installation of quick coupler:
Fig.6
Fig.7
*Special pipelines connection (it is suitable for quick coupler)
Strengthened tightening torque
160kgf.cm (63kgf.inch)
300kgf.cm (118kgf.inch)
500kgf.cm (197kgf.inch)
750kgf.cm (295kgf.inch)
1200kgf.cm (472kgf.inch)
200kgf.cm (79kgf.inch)
350kgf.cm (138kgf.inch)
550kgf.cm (216kgf.inch)
800kgf.cm (315kgf.inch)
1400kgf.cm (551kgf.inch)
Table 2 M inim um bending radius
N orm ial
diam eter(m m )
M inim um bending
radius(m m )
cooling capacity
D N 8(5/16")
D N 10-12
(1/2")
80(3")
100(4")
2100~2300W
(7000~8000BTU )
2500~5100W
(9000~18000BTU )
6100~7000W
(22000~24000BTU )
150(6")
D N 14-16
(5/8")
H igh pressure valve
Valve core cap
Low pressure valve
Q uick coupler
(w rapping w ith insulating cotton)
