*S election of installation positions for outdoor unit*
* To install the outdoor unit at the places w hich can stand the load of the m achine w eight and w ill
not cause big vibrations and noises;
* To install the unit at the places not to be exposed to rain or direct sunshine, and the places w ith
good ventilation;
* The noises generated from the unit w ill not affect the neighboring places;
* D o not install the unit on non-m etal fram e;
* N ot to install the unit at the places w here there m ight occur the generation, inflow , stay or
leakage of inflam m able gases;
* Pay attention to the drainage of the condensed w ater from the base plate during operations;
* To avoid the air outlet being directly against the w ind.
D etailed space requirem ents around the outdoor unit
1. W hen there are obstacles above
the unit
2. W hen the front (air outlet) is open 3. W hen there are obstacles only in
the front (air outlet)
4. W hen there are obstacles at the front and rear sides.
5. W hen there are obstacles all around
the unit on four sides.
Although the top side is open, the
installation is not to be done if there
are obstacles all around.
Space for m aintenance
Show n as in the follow ing figure. Keep
the m aintenance space in front of the
unit.
500mm(1'8") min
100mm(4") min
500mm(1'8") min
200mm(8") min
500mm(1'8") min
500mm
(1'8")min
200mm
(8")min
Space for m aintenance
* At least tw o sides should
be kept open.
200mm(8") min
300mm(1') min
1000mm(3'4") min
100mm(4") min
