16

RL Series Feature String Nomenclature

:

S

IZE

V

LT

C

O

N

F

IG

A1

A2

A3

A4

B1

B2

B3

1A

1B

1C

1D

2

3

4

5A

5B

5C

6A

6B

6C

7

8

9

10

11

12

13

14A

14B

15

16

17

18

19

20

21

22

23

R L – 1 0 0 – 3 – 0 – B E 0 6 – 3 5 2 : B E B E – D 0 0 Q F Y – P 0 A – 0 D B B 0 0 0 – 0 0 – 0 B B 0 0 AB 0 B

G

EN

Model Options

Unit Feature Options

Feature 2: OUTSIDE AIR CONTROL

0 = None
A = 3 Position Actuator, Sensible
B = 3 Position Actuator, Enthalpy
C = Full Mod Actuator, Sensible
D = Full Mod Actuator, Enthalpy
E = DDC Actuator
F = Constant Volume OA
G = Constant Volume OA, 3 Pos Act, Sensible
H = Constant Volume OA, 3 Pos Act, Enthalpy
J = Constant Volume OA, Full Mod Act, Sensible
K = Constant Volume OA, Full Mod Act, Enthalpy
L = Constant Volume OA, DDC Act
M = CO

2

Override, 3 Pos Actuator, Sensible

N = CO

2

Override, 3 Pos Actuator, Enthalpy

P = CO

2

Override, Full Mod Actuator, Sensible

Q = CO

2

Override, Full Mod Actuator, Enthalpy

R = CO

2

Override, DDC Actuator

S = Dual Min Pos, Full Mod Act, Sensible
T = Dual Min Pos, Full Mod Act, Enthalpy
U = 2 Position Actuator

Feature 3: DISCHARGE LOCATIONS

0 = Bottom Discharge
A = Front Discharge
B = Back Discharge
C = Top Discharge
D = End Discharge

Feature 4: RETURN LOCATIONS

0 = Bottom Return
A = End Return
B = Front Return High CFM w/o ERW or PE
C = Front Return Low CFM w/o ERW or PE
D = Back Return High CFM w/o ERW or PE
E = Back Return Low CFM w/o ERW or PE
F = Front Return High CFM w/ ERW or PE
G = Front Return Low CFM w/ ERW or PE
H = Back Return High CFM w/ ERW or PE
J = Back Return Low CFM w/ ERW or PE
K = Bottom Return w/ RA Bypass, 2’ Box
L = Bottom Return w/ RA Bypass, 4’ Box
M=Bottom Return High CFM Or w/o RA on 100%
OA
N=End Return High CFM w/o ERW or PE

Feature 5: SUPPLY AIR BLOWER

5A: SUPPLY AIR BLOWER CONFIGURATION
0 = 1 Blower, Standard Eff
A = 2 Blowers, Standard Eff
B = 3 Blowers, Standard Eff
C = 4 Blowers, Standard Eff
D = 1 Blower, Prem Eff
E = 2 Blowers, Prem Eff
F = 3 Blowers, Prem Eff
G = 4 Blowers, Prem Eff
H = 1 Blower, Prem Eff, w/ 1 VFD
J = 2 Blowers, Prem Eff, w/ 1 VFD
K = 2 Blowers, Prem Eff, w 2 VFDs
L = 3 Blowers, Prem Eff, w/ 1 VFD
M = 3 Blowers, Prem Eff, w/ 3 VFDs
N = 4 Blowers, Prem Eff, w/ 1 VFD
Q = 4 Blowers, Prem Eff, w/ 4 VFDs
R = 4 Blowers, Prem Eff, w/ 2 VFDs
S = 1 Blower, Prem Eff, w/ 1 Field Installed VFD
T = 2 Blowers, Prem Eff, w/ 1 Field Installed VFD
U = 2 Blowers, Prem Eff, w/ 2 Field Installed VFDs
V = 3 Blowers, Prem Eff, w/ 1 Field Installed VFD
W = 3 Blowers, Prem Eff, w/ 3 Field Installed VFDs
Y = 4 Blowers, Prem Eff, w/ 1 Field Installed VFD
Z = 4 Blowers, Prem Eff, w/ 4 Field Installed VFDs
1 = 4 Blowers, Prem Eff, w/ 2 Field Installed VFDs
2 = 1 Blower, Prem Eff, w/ 1 VFD w/ Bypass
3 = 2 Blowers, Prem Eff, w/ 1 VFD w/ Bypass
4 = 2 Blowers, Prem Eff, w 2 VFDs w/ Bypass
5 = 3 Blowers, Prem Eff, w/ 1 VFD w/ Bypass
6 = 3 Blowers, Prem Eff, w/ 3 VFDs w/ Bypass
7 = 4 Blowers, Prem Eff, w/ 1 VFD w/ Bypass
8 = 4 Blowers, Prem Eff, w/ 4 VFDs w/ Bypass
9 = 4 Blowers, Prem Eff, w/ 2 VFDs w/ Bypass
