RL Series Feature String Nomenclature
:
S
IZE
V
LT
C
O
N
F
IG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R L – 1 0 0 – 3 – 0 – B E 0 6 – 3 5 2 : B E B E – D 0 0 – Q F Y – P 0 A – 0 D B B 0 0 0 – 0 0 – 0 B B 0 0 AB 0 B
G
EN
Model Options
Unit Feature Options
Feature 1: RETURN/OUTSIDE AIR
1A: RETURN/OUTSIDE AIR SECTION
0 = Standard, Manual Outside Air
A = Economizer
B = Econ with Power Exhaust
C = Econ with Power Return
D = Energy Recovery Wheel (Total), Small
E = ERW (Total), Medium
F = ERW (Total), Large
G = ERW (Total), Extra Large
H = ERW (Sens), Small
J = ERW (Sens), Medium
K = ERW (Sens), Large
L = ERW (Sens), Extra Large
M = 100% Outside Air (No Return Air)
N = Motorized Outside Air (w/ Return Air)
P = Motorized Outside Air (No Return Air)
Q = Power Return + ERW (Total) Small
R = Power Return + ERW (Total), Medium
S = Power Return + ERW (Total), Large
T = Power Return + ERW (Total), Extra Large
U = Power Return + ERW (Sens), Small
V = Power Return + ERW (Sens), Medium
W = Power Return + ERW (Sens), Large
Y = Power Return + ERW (Sens), Extra Large
Z = Power Return, Plenum
1B: RETURN AIR BLOWER
CONFIGURATION
0 = None
A = 1 Blower, Standard Eff
B = 2 Blowers, Standard Eff
C = 1 Blower, Premium Eff
D = 2 Blowers, Premium Eff
E = 1 Blower, Premium Eff, 1 VFD
F = 2 Blowers, Premium Eff, 1 VFD
G = 2 Blowers, Premium Eff, 2 VFDs
H = 1 Blower, Premium Eff, 1 Field Installed VFD
J = 2 Blowers, Premium Eff, 1 Field Installed VFD
K = 2 Blowers, Premium Eff, 2 Field Installed VFDs
L = 1 Blower, Premium Eff, 1 VFD w/ Bypass
M = 2 Blowers, Premium Eff, 1 VFD w/ Bypass
N = 2 Blowers, Premium Eff, 2 VFDs w/ Bypass
1C: RETURN AIR BLOWER
0 = None
A = 36” Axial Flow, 6 Blades
B = 42” Axial Flow, 9 Blades
C = 42” Axial Flow, 12 Blades
D = 48” Axial Flow, 16 Blades
E = 27” Backward Curved
F = 30” Backward Curved
G = 33” Backward Curved
H = 36.5” Backward Curved
J = 42.5” Backward Curved
1D: RETURN AIR MOTOR
0 = None
D = 3 hp, 1170 rpm
E = 5 hp, 1170 rpm
F = 7.5 hp, 1170 rpm
G = 10 hp, 1170 rpm
H = 15 hp, 1170 rpm
J = 20 hp, 1170 rpm
K = 25 hp, 1170 rpm
L = 30 hp, 1170 rpm
M = 40 hp, 1170 rpm
N = 50 hp, 1170 rpm
T = 3 hp, 1760 rpm
U = 5 hp, 1760 rpm
V = 7.5 hp, 1760 rpm
W = 10 hp, 1760 rpm
Y = 15 hp, 1760 rpm
Z = 20 hp, 1760 rpm
1 = 25 hp, 1760 rpm
2 = 30 hp, 1760 rpm
3 = 40 hp, 1760 rpm
4= 50 hp, 1760 rpm
