Installation Instructions QMP1L
3
LEGEND
TOOLS REQUIRED FOR INSTALLATION
PARTS
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Phillips Screwdriver
Destornillador Phillips
Kreuzschlitzschraubendreher
Chave de fendas Phillips
Cacciavite a stella
Kruiskopschroevendraaier
Tournevis à pointe cruciforme
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clй а tête hexagonale
#2
3/32" (included)
5/32" (included)
3/16" (included)
A (1)
[Attachment plate]
B (1)
[Bracket]
D (1)
[Laptop tray
E (2)
[Array clamp, inner]
F (2)
[Array clamp, outer]
G (1)
[Cable management cover]
H (1)
[Pivot pin]
J (2)
10-24
K (2)
#10
L (4)
1/4-20 x 3/4"
M (1)
5/16-18 x 3-1/2"
N (1)
10-24 x 1/2"
P (2)
8-32 x 3/8"
C (1)
[Height-adjust assembly]
Q (1)
3/32" R (1)
5/32" S (1)
3/16"
assembly]
T (1) U (1)
V (1)
5/16"
W (2)
.018"
.094" .031
