I N S T A L L A T I O N I N S T R U C T I O N S
Flat Panel Display Security Kit
(FSA-1009 and KSA-1009)
The flat panel display security kit replaces exposed
hardware with security hardware.
NOTE: In some installations (i.e. single arm mount) not
all fasteners included in this kit will be required.
The security accessory kit can be used on most flat
panel configurations.
The pivot/pitch mount and mounts that are equipped with
a swing arm use the 4-inch security pivot bolts. Mounts
that are equipped with a height-adjustable arm use the
5-inch security pivot bolts. Some configurations can use
both the 4-inch and 5-inch security pivot bolts.
The security accessory kit is available for F-Series
mounts and K-Series mounts.
Security Parts Kit
BEFORE YOU BEGIN
CAUTION: To prevent damage to the mount, which could affect or void the Factory warranty, thoroughly
study all instructions and illustrations before you begin to install the mount brackets. Pay particular
attention to the “Important Warnings and Cautions” on Page 2.
If you have any questions about this installation, contact Chief Manufacturing at 1-800-582-6480 or 952-894-6280.
