CHIEF TA250 - Manual (Page 3)

Installation Instructions TA100/200/250
3
DIMENSIONS (CONTINUED)
22.16
DISTANCE TO C/L OF
TS5XXX SERIES
SWING ARMS
562.9
21.85
DISTANCE TO C/L OF
THE TS3XXX SERIES
HIGHEST EXTENSION
22.16
DISTANCE TO C/L OF
TS5XXX SERIES
SWING ARMS
562.9
21.85
DISTANCE TO C/L OF
THE TS3XXX SERIES
LOWEST EXTENSION
WITH EXTENDER BRACKET
4.50
HEIGHT
ADJUSTMENT
114.3
15.41
DISTANCE TO C/L OF
TS5XXX SERIES
HIGHEST EXTENSION
WITHOUT EXTENDER BRACKET
8.00
203.2
4.00
101.6
.28
7.1
4.00
101.6
1.25
31.8
.25
6.4
7.25
184.2
SHELF CAN BE USED
EITHER ABOVE OR BELOW
TA200
21.85
DISTANCE TO C/L OF
TS3XXX SERIES
SWING ARMS
555
22.16
HIGHEST EXTENSION
17.66
DISTANCE TO C/L OF
TS5XXX SERIES
SWING ARMS
448.6
17.35
DISTANCE TO C/L OF
TS3XXX SERIES
LOWEST EXTENSION
WITH EXTENDER BRACKET
4.50
HEIGHT
ADJUSTMENT
114.3
15.10
DISTANCE TO C/L OF
TS3XXX SERIES
HIGHEST EXTENSION
WITHOUT EXTENDER BRACKET
12.00
304.8
6.00
152.4
1.90
48.1
4.00
101.6
.28
7.1 1.25
31.8
.25
6.4
3.65
92.6
7.25
184.2
SHELF CAN BE USED
EITHER ABOVE OR
BELOW THE SCREEN
TA250
