Installation Instructions TS110SU/TS118SU
3
DIMENSIONS - TS110SU
DIMENSIONS - TS118SU
8.55
217.3
SCREEN CENTER
COMPATIBLE MOUNTING PATTERNS INCLUDE:
75 X 75, 100 X 100, 200 X 100, 200 X 200
1.49
37.9
MINIMUM
DISTANCE
FROM WALL
9.85
250.1
MAXIMUM
EXTENSION
FROM WALL
12.0°
MAX
7.37
187.1
9.09
230.9
.08
FACEPLATE
THICKNESS
90 PAN
LEFT/RIGHT
6.24
158.6
.27
6.7
2.62
66.5
SCREEN
CENTER
TO TOP
LAG BOLT
9.51
241.6
6.43
163.3
SCREEN CENTER
COMPATIBLE MOUNTING PATTERNS INCLUDE:
75 X 75, 100 X 100, 200 X 100, 200 X 200
1.50
38
MIN.
DISTANCE
FROM WALL
18.01
457.5
MAX
EXTENSION
FROM WALL 12.0°
MAX
TILT
6.05
153.7
2.49
63.2
1.06
26.9
9.09
230.9
PAN
LEFT/RIGHT
.27
6.73
1.00
25.4
SCREEN
CENTER
TO TOP
LAG BOLT
