Hunter 99093, 99094 4-Light Fitter With Glass - Manual (Page 4)

MA008-01 • 08/15/13
1.888.830.1326
4
Using the single pin connectors, connect
the black or blue wire from the fan to the
black wire from the light kit. Connect the
white wire from the fan to the white wire
from the light kit.
TYPE-A ASSEMBLY INSTRUCTIONS
Do not allow the light kit to hang
only by the wire connections!
If your fan does not have pin connectors on the
wires coming from the switch housing, install
the wiring harness provided. Using the provided
wire connectors connect the white wire from the
fan to the white wire from the wire harness and
connect the black or blue wire from the fan to
the black wire from the wire harness.
Wire
Connector
Switch
Housing
Remove the pre-installed light kit screws
and replace them with the longer light
kit screws provided.
Lift the light kit up to meet the lower
switch housing. Align the light kit screws
with the threaded holes in the lower
switch housing. Tighten screws securely.
Light Kit
Screw
Light Kit
Screw
1 2
3 4
Wire
Harness
