Wiring
FRO
M FAN
FR
OM
CEILING BRA
CK
ET
FROM FAN
Using an orange wire
connector from
the hardware bag,
connect the 3 grounding
wires (green, green/
yellow stripe, or bare
copper) coming from the
ceiling, downrod, and
hanging bracket.
(G
rounding)
G
reen/Y
ello
w
Strip
e
Green/Yellow
Stripe
W
hit
e
Black
(G
rounded)
Note: To connect the wires,
hold the bare metal leads
together and place a wire
connector over them, then twist
clockwise until tight.
Using the orange wire
connectors from
the hardware bag, connect
the black wire (ungrounded)
from the ceiling to the black
and the blue wires from the
fan. Connect the white wire
(grounded) from the ceiling to
the white wire from the fan.
Using the orange wire
connectors from
the hardware bag,
connect the white wire
(grounded) from the
ceiling to the white wire
from the fan.
Connect the black wire
(ungrounded) from the
ceiling to the black wire
from the fan. Connect the
second (ungrounded) wire
from the ceiling to the blue
wire from the fan.
FROM FAN
Whit
e
(Ungr
ounded)
Black
Blue
(Grounded
)
FR
OM CEILING
(Ungrounded
)
Blue
For Dual Switches
For a Single Switch
FR
OM CEILING
FR
OM CEILING
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box. Refer to CAUTION c.1 on pg. 2
10
M0042-01 • 01/29/14 • © Hunter Fan Company
