SPECIFICATIONS
GENERAL Model: American Audio
®
UCD-200 - Professional Compact Disc/USB Player
System: Dual, CD Tray Loading, Digital Compact Disc Audio Player.
Disc type: Standard compact discs (5 in /12cm and 3in/8cm discs)
Dimensions: Player unit: 19” (w) x 3.49” (H) x 10.5” (D)
482mm (w) x 88.8mm (H) x 267mm (D) (without feet)
Control unit: 19”(w) x 3.7” (H) x 3.5” (D)
482mm (w) x 94mm (H) x 91.2mm (D) (without feet)
Installation: Place on flat surface or mount in flat case
weight: Player unit: 10.14 Lbs. / 4.6kgs
Control unit: 3.75 Lbs. / 1.7kgs
Power supply: AC 100 - 240V, 50/60Hz
Power consumption: 16w
Pitch control range: +/-4%, +/-8%, +/-16%, and 100% (100% only applies to Standard CD's)
Pitch bend: +/-4%, +/-8%, +/-16%, and 100% (100% only applies to Standard CD's)
Pitch accuracy: 0.1%
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% RH (non-condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Accessories: Dual RCA Cable (for left and right channels)
Control 1/8” miniplug type (3 feet)
AUDIO SECTION
quantization:
16 bit linear per channel
Sampling rate: 44.1 kHz at normal pitch
Over sampling rate: 8 times over sampling 1 bit D/A converter
D/A conversion 16 bit
Frequency response: 20Hz to 20KHz +/-0.4dB (For CDDA)
Output level: 2.0Vms +/-0.5dB
Load impedance: 47k ohm or more
AUDIO CHARACTERISTICS (TEST DISC: TCD-782 & TCD-781; USB TEST FORMAT: MP3, 128KBPS;
LOAD=100Kohm):
ITEM
NOMINAL LIMIT CONDITION
Output level (CD): 2Vrms +/-0.5dB 2Vrms+/-1dB 1KHz, 0dB
Output level (USB): 1.85Vrms +/-0.5dB 1.85Vrms+/-1dB 1KHz, 0dB
Channel balance: within 0.2dB within 1dB 1KHz, 0dB
Frequency response (CD) 17-20KHZ +/-0.4dB 17-20KHZ +/-1dB 0dB OUTPUT (TCD782, TRK2/3/7)
Frequency response (USB) 17-16KHZ +/-0.2dB 17-16FKHZ +/-1dB 0dB OUTPUT (TCD781, TRK1/4/16)
De-emphasis response (CD): -20dB +/-0.2dB -20dB +/-1dB 16KHz,-20dB
Channel separation*2: 93dB 85dB 1KHz, 0dB
T.H.D. + NOISE*1 (CD): 0.008% 0.015% 1KHz, 0dB
T.H.D. + NOISE*1 (USB): 0.007% 0.015% 1KHz, 0dB
S/N ratio (IHF-A)*2 (CD): 126dB 90dB 1KHz, 0dB
S/N ratio (IHF-A)*2 (USB): 85dB 80dB 1KHz, 0dB
Dynamic Range*2 (CD): 92dB 88dB 1KHz, -60dB
NOTE: *1 with 20KHz low pass filter.
*2 with 20KHz low pass filter, "IHF-A" weighted
CD SEARCHING TIME (TEST DISC: TCD-792)
ITEM
NOMINAL LIMITS CONDITION
Short access time 2 sec 4 sec Play next track
Long access time 4 sec 6 sec Track 1 ->Track 20 / Track 20 ->Track 1
CD recover time 1 sec 2 sec CD play interrupted by mechanical shock
PLAyABILITy
ITEM
NOMINAL LIMIT CONDITION
Interruption 1mm 0.7mm TCD-725
Black dot 1mm 0.6mm TCD-725
Finger prints 75um 65um TCD-725
Eccentricity 140um 140um TCD-712, w/O TRACK JUMP
Vertical deviation 1mm 0.5mm TCD-731R
Scratch 2mm 1.2mm TCD-721, w/O TRACK JUMP
