API Delevan CM7560 & CM7560R - Manual

DA
SH
NU
MB
ER
*
L (µ
H),
L1
or
L2
@
1 k
Hz
±2
5%
CU
RR
EN
T R
AT
IN
G
MA
XIM
UM
(A
MP
S)
LE
AK
AG
E IN
DU
CT
AN
CE
MA
XIM
UM
(µ
H)
DC
R
ES
IST
AN
CE
MA
XIM
UM
(O
HM
S)
SERIES
CM7560R
CM7560
PC Mount Common Mode Choke
Physical Parameters
Inches Millimeters
A 0.860 ± 0.025 21.8 ± 0.64
B 1.070 ± 0.050 27.2 ± 1.27
C 0.830 ± 0.030 21.1 ± 0.76
D 1.060 (Ref. only) 26.9 (Ref. only)
E 0.040 ± 0.025 1.0 ± 0.64
F 0.025 Sq. (Typ.) 0.64 Sq. (Typ.)
G 0.400 ± 0.010 10.2 ± 0.3
H 0.175 ± 0.015 4.4 ± 0.38
J 1.03 (Ref. only) 26.2 (Ref. only)
K 0.400 ± 0.010 10.2 ± 0.3
L 0.630 + 0.010 16.0 ± 0.3
Operating Temperature Range –55°C to +125°C
Current Rating at 85°C Ambient 40°C Rise
Mechanical Configuration Tape wrapped winding
sections; varnish impregnated assembly
Notes 1) Inductance in table is for either Ll or L2.
2) Leakage Inductance tested at Ll with L2 shorted or at L2
with Ll shorted.
3) Windings balanced within 1%.
Tra
ns
fo
rm
ers
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: [email protected] • www.delevan.com
SERIES CM7560 FERRITE CORE
-563
-683
-823
-104
-124
-154
-184
-224
-274
-334
-474
-564
-684
-824
-105
-125
-155
-185
-225
-275
-335
-395
-475
-565
-685
-825
-106
-126
-156
-186
-226
-276
-336
-396
-476
-566
-686
-826
-107
-127
-157
0.013
0.013
0.013
0.013
0.015
0.015
0.019
0.020
0.025
0.025
0.030
0.035
0.040
0.060
0.065
0.095
0.115
0.125
0.170
0.180
0.320
0.400
0.450
0.500
0.600
0.750
0.800
0.900
1.00
1.30
1.50
1.80
2.20
2.60
3.00
4.00
5.00
5.50
6.40
7.80
9.00
56
68
82
100
120
150
180
220
270
330
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
22000
27000
33000
39000
47000
56000
68000
82000
100000
120000
150000
5.5
5.5
5.5
5.5
5.5
5.5
4.5
4.5
4.5
3.5
3.5
3.5
3.5
2.8
2.8
2.2
1.7
1.7
1.4
1.4
1.1
1.1
0.88
0.88
0.88
0.88
0.70
0.70
0.70
0.55
0.55
0.44
0.44
0.44
0.44
0.35
0.27
0.27
0.27
0.22
0.22
3.5
3.5
3.5
3.5
4.5
6.0
7.0
7.5
9.0
12
14
18
20
24
30
35
40
45
55
75
90
100
130
175
220
230
250
300
350
425
475
550
650
800
900
1100
1300
1800
2100
2600
3000
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Actual Size
Marking DELEVAN; part number.
Example: CM7560-563
DELEVAN
CM7560-563
Packaging Bulk only
1/2009
