API Delevan CM6560 & CM6560R - Manual

Actual Size
DA
SH
NU
MB
ER
*
L1
or
L2
IN
DU
CT
AN
CE
+35
%
/ -2
5%
(µ
H)
RA
TE
D R
MS
C
UR
RE
NT
(A
MP
S) M
AX
IM
UM
LE
AK
AG
E IN
DU
CT
AN
CE
TY
PIC
AL
(µ
H)
DC
R
ES
IST
AN
CE
MA
XIM
UM
(O
HM
S)
Mechanical Configuration
A flat top surface mount case with excellent coplanarity of
terminals.
Physical Parameters
Inches Millimeters
A 0.495 ± 0.010 12.6 ± 0.25
B 0.630 ± 0.010 16.0 ± 0.25
C 0.150 ± 0.010 3.81 ± 0.25
D 0.620 ± 0.010 15.8 ± 0.25
E 0.310 ± 0.010 7.88 ± 0.25
F 0.030 ± 0.010 0.76 ± 0.25
G 0.070 (Ref. only) 1.78 (Ref. only)
Electrical Configuration
1) Inductance and DCR in table is for either L1 or L2.
2) Leakage Inductance tested at L1 with L2 shorted or at
L2 with L1 shorted.
3) Windings balanced within 2%
4) Inductance tested @ 10 kHz
Operating Temperature Range –55°C to +105°C
Electrical Characteristics Measured at +25°C
Rated RMS Current Based upon 40°C temperature rise
from 25°C ambient.
Maximum Power Dissipation at 25°C 0.725 Watts
Inductance Tolerance Units are supplied to the tolerance
indicated in the tables @ 10kHz.
Dielectric Withstanding Voltage
500 V RMS, 60Hz
Tra
ns
fo
rm
ers
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: [email protected] • www.delevan.com
SERIES CM6560 FERRITE CORE
-104
-184
-334
-504
-754
-105
-185
-225
-335
-505
-755
-106
-126
-156
0.9
1.2
2.7
4.5
6.8
8.6
13.0
19.0
18.0
26.0
35.0
45.0
55.0
68.0
100
180
330
500
750
1000
1800
2200
3300
5000
7500
10000
12000
15000
8.50
7.00
4.80
3.60
3.00
2.40
1.90
1.50
1.20
0.95
0.75
0.55
0.45
0.35
0.005
0.007
0.015
0.023
0.034
0.047
0.080
0.105
0.160
0.240
0.360
0.530
0.730
1.100
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Marking DELEVAN; CM6560, inductance with units. Note: An R after
CM6560 indicates a RoHS component. A white dot indicates the location
of pin 1.
Example: CM6560R-104
DELEVAN
CM6560R
100 uH.
Packaging Tape & reel (24mm): 13" reel, 350 pieces max.; 7" reel not
available
Weight (Grams) 4.0 (Ref.)
SERIES
CM6560R
CM6560
Surface Mount
Common Mode Choke
1/2009
API_newlayouts_single:APIcatalog_newlayouts 8/27/10 10:59 AM Page 130
