API Delevan CM6149 & CM6149R User Manual
Series, Tra ns fo rm ers, Surface mount low profile cm choke

RA
TE
D R
MS
C
UR
RE
NT
(A
MP
S) M
AX
IM
UM
LE
AK
AG
E IN
DU
CT
AN
CE
TY
PIC
AL
(µ
H)
L1
or
L2
IN
DU
CT
AN
CE
+35
%
/ -2
5%
(µ
H)
DC
R
ES
IST
AN
CE
MA
XIM
UM
(O
HM
S)
Tra
ns
fo
rm
ers
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: [email protected] • www.delevan.com
Actual Size
DA
SH
NU
MB
ER
*
Mechanical Configuration A flat top surface mount case
with excellent coplanarity of terminals.
Physical Parameters
Inches Millimeters
A 0.212 ± 0.010 5.38 ± 0.25
B 0.285 ± 0.010 7.24 ± 0.25
C 0.060 ± 0.010 1.52 ± 0.25
D 0.250 ± 0.010 6.35 ± 0.25
E 0.200 ± 0.010 5.08 ± 0.25
F 0.025 ± 0.010 0.64 ± 0.25
G 0.40 (Ref. only) 1.02 (Ref. only)
Electrical Configuration
1) Inductance and DCR in table is for either L1 or L2.
2) Leakage Inductance tested at L1 with L2 shorted
or at L2 with L1 shorted.
3) Windings balanced within 2%
4) Inductance tested @ 10 kHz
Operating Temperature Range -55°C to +105°C
Electrical Characteristics Measured at +25°C
Rated RMS Current Based upon 40°C temperaturerise
from 25°C ambient.
Maximum Power Dissipation at 25°C 0.200 Watts
Inductance Tolerance Units are supplied to the
tolerance indicated in the table.
Dielectric Withstanding Voltage 500 V RMS, 60Hz
SERIES CM6149 FERRITE CORE
-253
-473
-683
-104
-154
-224
-334
-474
-684
-105
-125
-155
-225
0.20
0.30
0.40
0.50
0.70
1.10
1.50
1.70
2.00
2.80
3.50
4.30
6.00
3.0
2.5
2.0
1.6
1.3
1.0
0.75
0.60
0.50
0.40
0.30
0.24
0.18
0.010
0.015
0.020
0.030
0.040
0.060
0.090
0.125
0.170
0.250
0.350
0.500
0.750
25
47
68
100
150
220
330
470
680
1000
1200
1500
2200
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
SERIES
CM6149R
CM6149
Surface Mount
Low Profile CM Choke
Marking DELEVAN; CM6149, inductance with units. Note: An R after
CM6149 indicates a RoHS component. A white dot indicates the location
of pin 1.
Example: CM6149-154
DELEVAN
CM6149
150 uH
Packaging Tape & reel (16mm):
13˝ reel, 800 pieces max.; 7˝ reel not available
Weight (Grams) 0.5 (Ref.)
1/2009
