Series, Surface mount filter bead, Su pp re ss ors

Actual Size (Max.)
SERIES
4221R -1, -2, -4
4221 -3
Surface Mount Filter Bead
DA
SH
NU
MB
ER
*
IM
PE
DA
NC
E (O
HM
S)
@
25
M
Hz
(M
IN
IM
UM
)
IM
PE
DA
NC
E (O
HM
S)
@
10
0 M
Hz
(±2
0%
)
Operating Temperature Range –55°C to +125°C
Current Rating 5 Amps max. (35°C Rise, 90° Ambient)
Material Ferrite bead with plated copper lead
Packaging Tape & reel
Series 4221-1 and 4221-3 (12mm)
Series 4221-2 and 4221-4 (16mm)
7" reel, 500 pieces max.; 13" reel, 4000 pieces max.
SERIES 4221R / 4221
-1
-2
-3
-4
Su
pp
re
ss
ors
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: [email protected] • www.delevan.com
22
45
22
43
47
95
42
85
A in. 0.197 +0.011/-0.028 0.374 +0.015/-0.028 0.217 +0.011/-0.028 0.350 +0.015/-0.028
mm. (5.0 +0.3/-0.7) (9.5 +0.4/-0.7) (5.5 +0.3/-0.7) (8.9 +0.4/-0.7)
B in. 0.120 ± 0.006 0.120 ± 0.006 0.117 ± 0.006 0.187 ± 0.006
mm. (3.05 ± 0.15) (3.05 ± 0.15) (2.97 ± 0.15) (4.75 ± 0.15)
C in. 0.120 +0.007/-0.015 0.120 +0.007/-0.015 0.138 +0.007/-0.015 0.138 +0.007/-0.015
mm. (3.05 +0.2/-0.4) (3.05 +0.2/-0.4) (3.50 +0.2/-0.4) (3.50 +0.2/-0.4)
D in. 0.059 ± 0.025 0.059 ± 0.025 0.059 ± 0.025 0.059 ± 0.025
mm. (1.50 ± 0.63) (1.50 ± 0.63) (1.50 ± 0.63) (1.50 ± 0.63)
E in. 0.050 ± 0.003 0.050 ± 0.003 0.050 ± 0.003 0.073 ± 0.003
mm. (1.25 ± 0.07) (1.25 ± 0.07) (1.25 ±0.07) (1.85 ± 0.07)
4221 - 3
4221 - 2
4221 - 1
4221 - 4
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
For more detailed graphs, contact factory
1/2009
