API Delevan 5393 & 5393R User Manual

Series, Po w er i nd uc to rs, High current radial leaded chokes

background image

Shown Approximately
at 50% of Actual Size

DA

SH

NU

MB

ER

*

IN

DU

CT

AN

CE

±10

%

H @

1.0

0 k

Hz

)

DC

R

ES

IST

AN

CE

MA

XIM

UM

(O

HM

S)

SE

LF

R

ES

ON

AN

T

FR

EQ

UE

NC

Y M

IN

.(M

Hz

)

CU

RR

EN

T R

AT

IN

G

MA

XIM

UM

(A

D

C) M

IN

. (M

Hz

)

SERIES

5393R

5393

High Current Radial Leaded Chokes

Operating Temperature Range -55°C to +125°C

(-55°C to +75°C @ full current)

Current Rating at 75°C Ambient 50°C Temperature Rise

Maximum Power Dissipation at +85°C 1.166 Watts Maximum

Inductance Measured @ 1 kHz with 0 ADC on Wayne Kerr 3245A,

or equivalent.

Incremental Current The amount of DC that decreases the inductance by

10% maximum relative to the 0 ADC.

Dielectric Withstanding Voltage 2500 Vrms Minimum winding to outside cover

1/4” from winding edge

Marking Delevan, 5393 or 5393R, dash number (per table) and inductance

tolerance letter

Leads Solder coated to within 1/8 inch of body

Mechanical Configuration Self leaded terminals, coated coil, shrink sleeve

encapsulated

Packaging Bulk only

Po

w

er I

nd

uc

to

rs

270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: [email protected] • www.delevan.com

SERIES 5393R AND 5393R

-504K

-204K

-603K

-154K

-393K

-923K

-503K

-243K

15.0

20.0

28.0

30.0

40.0

45.0

50.0

60.0

500

200

60

150

39

92

50

24

0.8

1.2

1.9

2.1

2.5

2.9

3.1

5.7

0.050

0.021

0.0085

0.0130

0.0048

0.0075

0.0045

0.0025

*Complete part # must include series # PLUS the dash #

For surface finish information,

refer to www.delevanfinishes.com

11/2010

dash number

Type

Typ. Weight (grams)

A(Max.)

B ±0.062 (1.57)

C ±0.062 (1.57)

D ±0.062 (1.57)

(E) Lead Diameter

-504K

1

305

2.45 (62.23)

1.45 (36.83)

0.980 (24.89)

1.95 (49.53)

0.082

-204K

2

310

2.45 (62.23)

1.45 (36.83)

0.980 (24.89)

-

0.102

-603K

2

160

2.45 (62.23)

1.02 (25.91)

0.770 (19.56)

-

0.102

-154K

2

470

2.45 (62.23)

1.65 (41.91)

1.080 (27.43)

-

0.129

-393K

2

210

2.45 (62.23)

1.15 (29.21)

0.820 (20.83)

-

0.129

-923K

2

650

2.55 (64.77)

1.92 (48.77)

1.210 (24.89)

-

0.162

-503K

1

420

2.55 (64.77)

1.57 (39.88)

1.050 (26.67)

2.10 (53.34)

0.162

-243K

2

270

2.45 (62.23)

1.27 (32.26)

0.890 (22.61)

-

0.162

Physical Parameters in Inches (Millimeters)
