API Delevan 5500 & 5500R - Manual

Actual Size
D
A
S
H
N
U
M
B
E
R
*
IN
D
U
C
TA
N
C
E
±1
0%
(µ
H
@
1
.0
0 k
H
z)
D
C
R
E
S
IS
TA
N
C
E
M
A
X
IM
U
M
(O
H
M
S
)
C
U
R
R
E
N
T R
AT
IN
G
M
A
X
IM
U
M
(A
D
C
)
IN
C
R
E
M
E
N
TA
L
C
U
R
R
E
N
T (
A
D
C
)
SERIES
5500R
5500
High Current Power Chokes
Physical Parameters
Inches Millimeters
A 1.020 to 1.080 25.91 to 27.44
B 0.480 to 0.510 12.20 to 12.96
C 0.520 Maximum 13.21 Maximum
D 0.240 Minimum 6.10 Minimum
E 0.120 to 0.160 3.05 to 4.07
F 0.500 (Ref. Only) 12.70 (Ref. Only)
G 0.250 (Ref. Only) 6.35 (Ref. Only)
Dimensions "A" and "C" and "G" are over the terminals.
Operating Temperature Range -55°C to +130°C
Current Rating at 85°C Ambient 45°C Temperature Rise
Maximum Power Dissipation at +85°C: 1.166 Watts Maximum
Inductance Measured @ 1 kHz with 0 ADC on Wayne Kerr
3245A, or equivalent.
Incremental Current The amount of DC that decreases the
Inductance by 5% maximum relative to the 0 ADC.
Dielectric Withstanding Voltage Meets MIL-STD-202,
Method 301, 1000 Vrms Minimum
Marking DELEVAN, INDUCTANCE VALUE and DATE CODE/LOT
SYMBOL (YYWWL). Note: An "R" before the date code/lot
symbol indicates a RoHS Compliant choke.
DELEVAN
3.9uH
R YYWWL
Thermal Shock Meets MIL-STD-202, Method 107,
Test Condition A-1 (-55°C to +130°C).
Mechanical Shock Meets MIL-STD-202, Method 213,
Test Condition I.
Vibration Meets MIL-STD-202, Method 204, Test Condition D
Solderability Meets MIL-STD-202, Method 208
Terminal Material and Final Finish
Series 5500R: (Tin - Silver - Copper) Sn96.5Ag3.0Cu0.5 over Copper (Cu)
Series 5500: (Tin - Lead) Sn63Pb37 over Copper (Cu)
Weight 13 Grams Maximum
Packaging Tape and Reel (44mm): 13” reel,
200 pieces max: 7” reel not available
Made In The U.S.A.
P
o
w
er
In
d
u
ct
o
rs
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: [email protected] • www.delevan.com
SERIES 5500R AND 5500
-392K
-472K
-562K
-682K
-822K
-103K
-123K
-153K
-183K
-223K
-273K
-333K
-393K
-473K
-563K
-683K
-823K
-104K
-124K
-154K
-184K
-224K
-274K
-334K
-394K
-474K
-564K
-684K
-824K
-105K
-125K
-155K
-185K
-225K
-275K
-335K
-395K
-475K
-565K
-685K
-825K
-106K
-126K
-156K
-186K
-226K
-276K
-336K
-396K
-476K
-566K
-686K
-826K
-107K
9.13
8.30
7.61
7.02
6.52
5.71
5.07
4.57
4.15
3.65
3.38
3.04
2.85
2.61
2.34
2.12
1.94
1.76
1.60
1.43
1.30
1.19
1.07
0.96
0.88
0.81
0.74
0.68
0.63
0.56
0.51
0.45
0.41
0.37
0.32
0.30
0.28
0.25
0.23
0.21
0.19
0.17
0.16
0.14
0.13
0.12
0.10
0.09
0.09
0.08
0.07
0.07
0.06
0.05
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1,000
1,200
1,500
1,800
2,200
2,700
3,300
3,900
4,700
5,600
6,800
8,200
10,000
12,000
15,000
18,000
22,000
27,000
33,000
39,000
47,000
56,000
68,000
82,000
100,000
11.91
11.14
9.50
9.10
8.74
7.88
7.43
7.05
6.72
6.43
6.30
5.96
5.66
5.41
4.81
4.08
3.88
3.44
2.96
2.78
2.57
2.48
2.10
1.97
1.86
1.59
1.40
1.32
1.24
1.08
1.01
0.92
0.81
0.75
0.68
0.63
0.59
0.51
0.48
0.42
0.39
0.37
0.33
0.30
0.26
0.23
0.21
0.20
0.18
0.17
0.16
0.14
0.12
0.11
0.007
0.008
0.011
0.012
0.013
0.016
0.018
0.020
0.022
0.024
0.025
0.028
0.031
0.034
0.043
0.060
0.066
0.084
0.113
0.129
0.150
0.162
0.226
0.257
0.288
0.393
0.504
0.570
0.643
0.844
0.977
1.18
1.50
1.76
2.13
2.53
2.84
3.79
4.24
5.75
6.44
7.30
9.34
10.7
14.8
18.0
22.7
25.7
29.7
33.7
38.0
52.8
67.3
76.0
OPTIONAL TOLERANCES: J = +/- 5% L = +/- 15%
The Suffix (Optional Tolerance “J” or “L”) should replace the “K”, in the dash number.
*Complete part # must include series # PLUS the dash #
