SERIES

8532R

8532

High Current Surface Mount Power Inductors

Mechanical Configuration
Units are encapsulated in a Surface Mount package, using

an epoxy molded case. High resistivity ferrite core, allows

for high inductance with low DC resistance.

Physical Parameters

Inches Millimeters

A 0.840 to 0.880 21.34 to 22.35

B 0.310 to 0.330 7.87 to 8.38

C 0.266 to 0.286 6.76 to 7.26

D 0.050 Min. 1.27 Min.

E 0.070 to 0.110 1.78 to 2.79

F 0.750 (Ref. only) 19.05 (Ref. only)

G 0.120 (Ref. only) 3.05 (Ref. only)

Dimensions “A” and “C” are over terminals.

Operating Temperature Range –55°C to +125°C

Current Rating 40°C Rise over 85°C Ambient

Maximum Power Dissipation at 85°C 0.50 Watts

Inductance
Measured at 1 VAC open circuit with no DC current.

Incremental Current The current at which the inductance

will decrease by a maximum of 5% from its initial zero DC

value.

Weight Max. (Grams) 2.5

Marking API/SMD; inductance with units and tolerance;
date code (YYWWL). Note: An R before the date code

indicates a RoHS component.

Example: 8532R-52L

API/SMD

18mH±15%

R 0901B

Packaging Tape & reel (44mm):
13" reel, 480 pieces max.; 7" reel not available

Made In the U.S.A.
